Description

MAXIMUM COOLING EFFICIENCY AND UPGRADED SKID PLATE

Your Ford Ranger features radiators and intercoolers, both of which require airflow to protect the engine and maintain performance.

Our bull bars have been designed to ensure that airflow is fully maintained, and as such you will find a number of air-rams built in which duct air to exactly where it is needed.

12,000LB WINCH COMPATIBLE

Industry standards recommend a winch that’s at least 1.5 times the weight of your vehicle, and with a standard GVM of 3350kg, the Next Gen Ford Ranger demands nothing less than 11,000lb winch. That’s why we’ve ensured the Raid bull bar is compatible with a 12,000lb winch.

RECOVERY POINTS INCLUDED AS STANDARD

We think recovery points are so important, we’ve included them in the bull bar.

Too often, those who think they don’t need recovery points find themselves in a situation needing them. And too often it results in resorting to dangerous recoveries off unrated points. At Ironman 4×4, we put your safety first and have included recovery points in each of our Bull Bars to suit the Next Gen Ranger.

The recovery points are manufactured from 16mm steel, featuring non-abrasive radius edges and an elongated hole for different types of shackles. Plus, they’re powder-coated red for high visibility and are rated to 5-tonne (per point).

BUMPER REPLACEMENT DESIGN
No cutting is required.

WINCH-READY
With flip-up number plate holder and optional hidden winch mount kit.

MINIMAL PROTRUSION
Adding just 115mm to the front of the vehicle.

MAINTAINS ALL OEM SAFETY FEATURES

Including parking sensors, blind-spot monitoring, radars, front and rear cameras and panoramic view monitoring.

ADDED EXTRAS
Includes an LED light bar holder, dual cube light holders on both sides of the vehicle with a stylish removable grill plate (lights optional).

WINCH COMPATIBILITY	Synthetic Winch Only
RECOVERY POINTS	Included – 16mm Rated Recovery Points
DRIVING LIGHT MOUNTS	Included. Optional 32″ Bright Sabre Single Row Lightbar and 20W Bright Cube Lights
ADR COMPLIANT	Yes
AIRBAG COMPATIBLE	Yes
SENSOR & RADAR COMPATIBLE	Yes
POWDER COATING	Matte Black Textured Finish
COLOUR CODING COMPATIBLE	Yes
